Sesuai untuk menapis kekotoran pepejal dan cecair di udara termampat di bawah 4.0MPa, penapis ketepatan gas tekanan tinggi mengamalkan teknologi pembuatan ketepatan, sepenuhnya mengingati keperluan teknologi tekanan tinggi. Diperbuat daripada keluli tahan karat 304, 316L, dan keluli karbon bersalut khas, ia dapat menyediakan elemen penapis prestasi 25, 5, 1, dan 0.01UM dan diaktifkan untuk memenuhi pelbagai keperluan khas pelanggan. Ia direka menggunakan prinsip aerodinamik untuk memastikan penurunan tekanan medium penapis diminimumkan.
Siasatan
Penerangan Produk
| Model penapis | Aliran m³/m | Antara muka | h (w) | C (diameter) | Outlet kumbahan |
| BH-001* | 1 | 1/2 '' 3/4 '' 1 '' | 230mm | 80mm | 1/2 |
| BH-002* | 2 | 1/2 '' 3/4 '' 1 '' | 230mm | 80mm | 1/2 |
| BH-003* | 3 | 1 '' | 260mm | 106mm | 1/2 |
| BH-005* | 5 | 1-1/2 '' | 405mm | 115mm | 1/2 |
| BH-007* | 7 | 1-1/2 '' | 505mm | 115mm | 1/2 |
| BH-010* | 11 | 1-1/2 '' | 620mm | 115mm | 1/2 |
| BH-013* | 13 | 2 '' | 620mm | 140mm | 1/2 |
Kes Pembinaan
Hubungi Kami untuk Butiran Lanjut
Jangan teragak-agak untuk menghubungi apabila anda memerlukan kami!
